EtherCAT the high-performance industrial Ethernet protocol revolutionizing automation. This comprehensive course equips engineers, technicians, and developers with end-to-end expertise to understand EtherCAT networks and how they work. This course concentrate more on the theoretical part of EtherCAT.

  Key Modules:

• Fundamentals: Core principles, frame structure, and "process on the fly" operation, process data
• Implementation: Network topologies (daisy-chain, ring), ESI/ENI configuration, and PDO mapping. Main-Device and Sub-Device
• Mailbox Protocols: CoE (CANopen over EtherCAT), EoE (Ethernet over EtherCAT),  FoE (File Access over EtherCAT), SoE (Servo over EtherCAT) and VoE (Vendor over EtherCAT).
• Timing and Distributed Clocks (DC)
• Error Detection and Diagnosis

  Ideal For:
Automation engineers, PLC programmers, and robotics specialists preparing for high-speed, real-time industrial applications or any newbies diving into the automation World.

Enroll to understand the theory behind EtherCAT!

Perfect for: SPS programmers, application developers in an automatisation field.

We won't let any questions unanswered, so please ask and ask and ask.

Also don't refrain from sending us your feedback, it can make the course better. I am open to extend the course with any missing topics and thanks for diving into the EtherCAT world.

This course is not intended for people looking for praxis. It explains more the theory behind EtherCAT, but with small TwinCAT examples.
